AQUA U-Drive
- Booster set.
- Exclusive solution for 1 pump.
- Variable speed and constant pressure.
- Maximum reliability and robustness.
- Calibrated and factory-tested equipment.
- Maximized automation for continuous, efficient, and quiet operation.
- Reduced maintenance.
- Control by high-reliability pressure transducer.
- Compact and sustainable solution.
- Ideal for building applications.
- “Plug-and-Pump”.
System Customization:
- It can be customized according to customer and/or application requirements.
APPLICATIONS
- Water pressure boosting in commercial applications
- Hydraulic distribution network
- Water supply to residential and public areas
PUMPS TO BE USED
- Type: Vertical Multistage
- Series: BMVE| BMVET| BMVETi
- Installed power: up to 15 kW
ADDITIONAL OPTIONS AVAILABLE INCLUDE
- IE4 efficiency class electric motors.
- Pressure switch control bypass
- Membrane hydropneumatic reservoir in AISI 304
- Membrane hydropneumatic reservoir in fiber glass
- Suction manifold
- General shutoff valves (suction and compression)
- Dry-run protection kit
SYSTEM CONSTRUCTION
- Baseplate: Painted steel plate
- Painting: water-based, moisture-resistant
- Discharge manifold
- Valves: Pump shutoff and check valves (compression)
- Accessories: pressure transducer and analog pressure gauge (compression)
- Hydropneumatic reservoir: Replaceable membrane
- U-DRIVE control panel: For general cutting, supply and reception of digital signals
- Level switch: Dry run protection.
WORKING LIMITS(50 Hz)
- Maximum Flow: up to 170 m³/h
- Head: up to 235 m
- Maximum fluid temperature: From -15ºC up to 120ºC
- Maximum ambient temperature: 40ºC
- Maximum operating pressure: Up to 25 bar
